Standard and available convenience features on the BMW Motorrad R 1300 R
Detailed technical data, dimensions, chassis, transmission and electrical specifications
| Engine Type | 1,300 cc, air/liquid-cooled, 2-cylinder boxer, DOHC with BMW ShiftCam |
| Max Power | 145 hp @ 7,750 rpm |
| Max Torque | 149 Nm @ 6,500 rpm |
| Compression Ratio | 13.3:1 |
| Fuel System | Electronic Fuel Injection (EFI), ride-by-wire |
| Transmission | 6-speed manual |
| Final Drive | Shaft (Cardan) drive |
| Cooling System | Air/liquid-cooled |
| Fuel Type | Premium unleaded petrol |
| Length | 2,145 mm approx. |
| Width | 880 mm approx. |
| Height | 1,145 mm approx. |
| Wheelbase | 1,515 mm approx. |
| Seat Height | 785 mm (options available) |
| Ground Clearance | 175 mm approx. |
| Kerb Weight | 239 kg approx. |
| Fuel Tank Capacity | 17 litres |
| Front Brake | Dual 310 mm discs, 4-piston radial calipers |
| Rear Brake | Single 285 mm disc, 2-piston floating caliper |
| ABS | Integral ABS Pro (cornering ABS) |
| Front Tyre | 120/70 R17 |
| Rear Tyre | 190/55 R17 |
| Wheels | Alloy wheels, 17-inch |
| Frame | Steel main frame with bolt-on rear frame, load-bearing engine |
| Front Suspension | 47 mm upside-down telescopic fork |
| Rear Suspension | BMW EVO Paralever single-sided swingarm |
| Suspension Travel | Front ~125 mm, Rear ~140 mm |
| Dynamic Suspension Adjustment (DSA) | Optional, adjusts damping, preload, and spring rate |
| Battery | 12V maintenance-free |
| Headlight | LED (adaptive optional) |
| Tail Lamp | LED |
| Indicators | LED |
| DRLs | Available |
| USB Charger | Available (optional) |
